Modulite
LEGRESTS
Our wide range of power and manual legrests are available in an array
of sizes and styles including individual legrests and central foot
platforms to help secure and position clients' legs. In addition, we offer
a multitude of legrest hangers to accommodate your legrest choice.
Power legrests may be programmed to operate in one of the two
following configurations:
Individual (legrests operate independently),
l
Combined (legrests operate in unison)
l
2.3 Manual Positioning Function
The seating system offers the following functions:
FIXED PIVOT TILT
At the fixed pivot tilt function the centre of gravity is shifted backward
by the fixed pivot axis as the seat tilts back. Typical tilt range is 0° up to
15°.
RECLINE
The recline function enables users to infinitely change the seat to back
angle of their system within a set range. Typical recline angle range is
90° up to 120°.
LEGRESTS
Our wide range of power and manual legrests are available in an array
of sizes and styles including individual legrests and central foot
platforms to help secure and position clients' legs. In addition, we offer
a multitude of legrest hangers to accommodate your legrest choice.
8
2.4 Driving and Seating Limitations (LiNX System)
DANGER!
Risk of Severe Injury or Death
The angle at which the limit switches/lockouts are set is
critical to the safe operation of the system.
— Invacare will not be liable for any injuries or damage
sustained when adjustments are made beyond the
factory recommended settings.
— To ensure proper set-up, adjustments to lockouts and
limits should only be performed by a qualified
technician.
— Never exceed the maximum recommended limits.
Lockouts and limit switches should be set up to best
meet the needs of the user without compromising the
overall stability of the wheelchair.
— Following any limit or lockout adjustments, always test
the seating system over the full range of motion (i.e. tilt,
recline, lifter) to verify the revised set-up is functioning
properly and ensure that there are no resulting stability
or interference issues.
Additional limits and lockout switches may be required for
more complicated/specialised seating systems. For information
on limits/lockouts that are not identified in this manual,
contact your provider.
For TDX SP2, drive and seating restrictions are only updated while
stationary.
