3.9.4 Adjusting Elan Headrest Hardware
Elan headrest hardware is highly adjustable. The illustration below
shows the possible adjustment ranges of the joints.
Upper multi-angle rotational
A
pivot
B Upper linkage
C Middle linkage
D Lower linkage
E Mounting post
Lower multi-angle rotational
F
pivot
1656515-G
360° rotation
l
80° tilt
l
180° rotation
l
100° rotation
l
180° rotation
l
360° rotation in 90°
l
increments
360° rotation
l
50° tilt
l
Installing
2.5 mm Allen key
l
4 mm Allen key
l
5 mm Allen key
l
1. Using hardware provided, align and
2. Install headrest pad (not shown) to
3. Loosen and remove lower D-Ring E from hardware.
4. Slide vertical mounting post B into clamp assembly and adjust
overall height of headrest pad to desired position. Tighten knob
D. F or proper set-up headrest should be adjusted to user's ear
height.
5. Adjust upper D-Ring C as required.
6. Once final height position is set, adjust lower D-Ring E so that it
rests flush with bottom of clamp assembly (to prevent slipping).
install headrest clamp assembly into
existing mounting holes in backrest
pan A.
headrest rod using mounting
hardware provided.
The headrest pad can be
adjusted to any desired angle
via the pivot ball at the end of
the headrest rod by loosening
and tightening the mounting
hardware.
