Modulite
Symptom
Intermittent seating system functions (day to
day, during tilt, during recline...)
Drive lockout (DLO) is not functioning
Limit switch not functioning properly
57
Probable Cause
Loose / faulty electrical connection
Faulty power harness
Faulty limit switch
Nearly exhausted battery (fluctuating
charge)
Loose / faulty electrical connection
DLO limit switch / mechanical switch is
not set properly
Faulty DLO limit switch
Loose / faulty electrical connection
Faulty limit switch
Limit switch is not set–up properly
Solutions
Check cable connections / check cable ties (too
tight / too loose).
Check / replace power harness.
Contact your provider.
Check / replace limit switch.
Contact your provider.
Check / replace battery.
Contact your provider.
Check connections.
Contact your provider.
Contact your provider.
Contact your provider.
Check connections.
Contact your provider.
Check/ replace limit switch.
Contact your provider.
Contact your provider.
1656515-G
