Modulite
Adjusting Hip Pad Height
You can adjust the hip pad height in two ways:
Via its mounting slots.
l
Via its bracket.
l
Via mounting slots
10 mm wrench
l
1.
2.
3. Insert hip pad bracket in other mounting slot.
4. Tighten screws.
32
Loosen the two screws A.
Remove hip pad bracket from mounting
slot via cut-out B.
Via bracket
5 mm Allen key
l
1.
2. Remove small friction link B.
3.
4. Insert friction link, friction cap, screw and tighten.
3.14 Adjusting / Removing Tray
WARNING!
Risk of Injury or Damage
If the power wheelchair is fitted with a tray or other
auxiliary equipment this could break free during t ransfer to
Remove upper screw and friction cap A.
Remove hip pad with bracket, turn
upside down and reinstall.
1656515-G
