a vehicle and cause damage or injury t o users in the event of
a collision.
— When possible, other auxiliary power wheelchair
equipment should be either secured to the p ower
wheelchair or removed from the power wheelchair and
secured in the vehicle during travel.
— If a tray is fitted, always remove it before t ransporting
the power wheelchair.
3.14.1 Adjusting Tray Laterally
A
1656515-G
1. Loosen wing screw A.
2. Adjust component to desired
position.
3. Tighten wing screw.
3.14.2 Adjusting Depth of Tray / Removing Tray
3.14.3 Swinging Tray Away to Side
The tray can be swivelled up and away to the side to allow the user to
get in and out of the power wheelchair.
CAUTION!
Risk of injury! When the tray is raised it does not
lock in place in this position!
— Do not tilt the tray up and leave it leaning in this
position.
— Never attempt to drive with the tray tilted up.
— Always lower the tray in a controlled manner.
3.15 Central Legrests — Manually Adjustable
3.15.1 Removing Legrest
You can remove central, manually adjustable legrest completely.
1. Loosen wing screw A.
2. Adjust component to desired
position (or remove it entirely).
3. Tighten wing screw.
3 Setup
33
