Symptom
System only operates in one direction
Remote will not function
Actuator keeps running
1656515-G
Probable Cause
Limit is exceeded (DLO, RDS, back angle,
elevating seat lockout)
Faulty limit switch
Limit switch is not set–up properly
Low voltage
Battery not charged
Remote not plugged in
Remote not turned on
Blown base fuse
Pinched switch harness
Solutions
Come within limit ranges.
Check / replace limit switch.
Contact your provider.
Contact your provider.
Contact your provider.
Charge batteries.
Inspect cable connection.
Turn on power to the remote via the keypad.
Contact your provider.
Inspect / replace fuse.
Inspect / adjust harness position to prevent
pinching.
Contact your provider.
7 Troubleshooting
