2 Components
2.1 Product Description
The following configurations may vary depending on country.
The Modulite seating system is offered with different seat types.
One Piece Seat Plate
The one piece seat plate is offered in different seat widths (380 mm or
430 mm). Individual width adjustment can be influenced by the choice
of the armrests.
The one piece seat plate is offered in different seat depths (410 mm,
460 mm or 510 mm). The seat depth of the one piece seat plate can be
adjusted manually. Refer to 3.11.2 Adjusting Seat Depth, page 29.
The one piece seat plate is offered in different pre-assembled seat
heights (435 mm, 460 mm or 485 mm). A manually height adjustment
must be made by a qualified technician. For more information about
height adjustment, refer to the service manual of the wheelchair.
Telescopic Seat Frame
The telescopic seat frame is offered with different options: a seat
plate, a sling seat or an universal adapter.
The seat width of the telescopic seat frame can be adjusted manually.
Refer to 3.11.1 Adjusting Seat Width, page 28.
The telescopic seat frame is offered in different seat depths (410 mm,
460 mm, 510 mm or 580 mm). The seat depth of the telescopic seat
frame can be adjusted manually. Refer to 3.11.2 Adjusting Seat Depth,
page 29.
1656515-G
The telescopic seat frame is offered in different pre-assembled seat
heights (435 mm, 460 mm or 485 mm). Individual height adjustment
can be made by the lifter, if the lifter is part of the configuration. A
manually height adjustment must be made by a qualified technician.
For more information about height adjustment, refer to the service
manual of the wheelchair.
2.2 Power Positioning Functions
The seating system offers the following functions:
FIXED PIVOT TILT
At the fixed pivot tilt function the centre of gravity is shifted backward
by the fixed pivot axis as the seat tilts back. Typical tilt range is 0° up to
20°.
CoG-TILT
The CoG (centre of gravity) tilt function compensates for weight shift
by sliding the pivot axis and entire seat assembly forward as the seat
tilts back. Typical tilt range is 0° up to 50°. For more information about
your specific configuration, refer to 8.1 Technical Specifications, page
59.
RECLINE
The recline function enables users to infinitely change the seat to back
angle of their system within a set range. Typical recline angle range is
90° up to 120°.
LIFTER MODULE
The lifter module allows users to raise their power positioning system
up to 300 mm above the lowest seat-to-floor height of their system.
The lifter is combined with a tilt function.
