4.4 Using LNX Powered Central Legrest with
Telescoping Footboard
Adjusting Angle
WARNING!
Pinch point
Risk of pinching when adjusting legrest angle.
— Keep top of legrest clear when adjusting legrest angle.
Lowering Footboard
NOTICE!
Lowering footboard until preset point could damage floor.
— Stop lowering footboard when it touches the floor.
You can lower the telescoping footboard until a preset point.
Depending on the wheelchair configuration, this point might not
exactly fit the seat-to-floor height but end a few millimeters above or
push a few millimeters into the floor.
Drive Lockout
NOTICE!
Driving the wheelchair with lowered footboard could
damage the legrest.
— As soon as you move the footboard, a drive lockout
engages.
1. To disengage drive lockout, retract footboard to top position.
