3.19 ADM Legrests
3.19.1 Swivelling Legrest Outward and / or Removing
The small unlocking button is located on the upper section of the
legrest. When the legrest is unlocked, it can be swivelled inward or
outward when getting into the wheelchair as well as being removed
completely.
A
1. Press the unlocking button A and
2. Remove the legrest in an upward
3.19.2 Setting Angle
CAUTION!
Risk of injury due to incorrect adjustment of the
footrests and legrests
— Before and during every journey it is imperative t o
ensure that the footrests contact neither the c astor
wheels nor the ground.
1656515-G
swivel the legrest outward.
direction.
CAUTION!
Risk of crushing
— Do not reach inside the swivelling range of the l egrest.
Raising
1. Pull the legrest upward until the
Lowering
A
1. Keep the legrest in the foot plate area,
desired angle has been achieved.
pull the lateral adjusting lever A and
lower the legrest slowly.
