- Page 1 Invacare® Modulite Supplement to power wheelchair user manual Seating System User Manual This manual MUST be given to the user of the product. BEFORE using this product, this manual MUST be read and saved for ...
-
Page 2: Table Of Contents
All rights reserved. Republication, duplication or modification in whole or in part is prohibited without prior written permission from Invacare. Trademarks are identified by ™ and ®. All trademarks are owned by or licensed to Invacare Corporation or its subsidiaries unless otherwise noted. - Page 3 3.11.2 Adjusting Seat Depth 3.19.1 Swivelling Legrest Outward and / or Removing 3.11.3 Adjusting Seat Angle 3.19.2 Setting Angle 3.12 Adjusting Lateral Trunk Support 3.19.3 Adjusting Length of Legrest 3.13 Adjusting Hip Support with Quick Release 3.19.4 Adjusting Calf Pads 3.14 Adjusting / Removing Tray 3.19.5 Adjusting Footrests 3.14.1 Adjusting Tray Laterally 3.20 Powered Elevating Legrests (ADE Legrests) 3.14.2 Adjusting Depth of Tray / Removing Tray 3.20.1 Swivelling Legrest Outward and / or Removing 3.14.3 Swinging Tray Away to Side 3.20.2 Setting Angle 3.15 Central Legrests — Manually Adjustable 3.20.3 Adjusting Length of Legrest 3.15.1 Removing Legrest 3.20.4 Adjusting Calf Pads 3.15.2 Setting Angle of Legrest 3.20.5 Adjusting Footrests 3.15.3 Setting Length of Legrest 3.21 Adjusting Standard 80° Legrest 3.15.4 Setting Angle of Footplate 4 Usage 3.15.5 Adjusting Calf Pads 4.1 Removing Armrest for Side Transfer 3.16 LNX Legrest 4.2 Removing / Inserting Hip Support with Quick Release 3.16.1 Setting Length of Legrest 4.3 Replacing Backrest Cushion 3.16.2 Setting Angle of Footplate 4.4 Using LNX Powered Central Legrest with Telescoping 3.16.3 Adjusting Footplate Width Footboard 3.16.4 Setting Angle of Foot Platform 5 Maintenance Schedule 3.16.5 Adjusting Calf Pads 3.17 Vari-F Legrest 6 After Use 3.17.1 Swivelling Legrest Outward and / or Removing 6.1 Reconditioning...
-
Page 4: 1 General
1 General For more information about the component, for example safety 1 General notices and recalls, contact your Invacare representative. See addresses at the end of this document. 1.1 About This Manual In case of a serious incident with the component, you should inform the manufacturer and the competent authority in your country. This document is a supplement to the product’s user documentation. This component itself does not bear a CE and a UKCA mark but is part 1.2 Symbols in This Manual of a product that complies with the Medical Device Regulation 2017/745, Class I and Part II UK MDR 2002 (as amended) Class I Symbols and signal words are used in this manual and apply to hazards concerning medical devices. It is therefore covered by the product’s CE or unsafe practices which could result in personal injury or property and UKCA marking. See the product’s user documentation for more damage. See the information below for definitions of the signal words. information. DANGER! Only use this component if you have read and understood this manual. Indicates a hazardous situation that will result in serious Seek additional advise from a healthcare professional who is familiar injury or death if it is not avoided. with your medical condition and clarify any questions regarding the correct use and necessary adjustment with the healthcare professional. WARNING! Indicates a hazardous situation that could result in serious Note that there may be sections in this document, which are not injury or death if it is not avoided. relevant to your component, since this document applies to all available models (on the date of printing). If not otherwise stated, each section in this document refers to all models of the component. CAUTION! Indicates a hazardous situation that could result in minor or Invacare reserves the right to alter component specifications without slight injury if it is not avoided. further notice. -
Page 5: Warranty Information
Modulite The user manual of the power wheelchair contains all relevant safety Tools information about the use of the power wheelchair including the Identifies required tools, components and items which are seating system. Be certain to read and follow these safety information. needed to carry out certain work. Other Symbols WARNING! (Not applicable for all manuals) Risk of Tipping UK Responsible Person The power wheelchair may tip over when you change its Indicates if a product is not manufactured in the UK. stability characteristics by changing your seating position. — Determine and establish your personal safety limits by Triman practicing bending, reaching and transferring activities in Indicates recycling and sorting rules (only relevant for the presence of a qualified healthcare professional France). before attempting active use of the wheelchair. 1.3 Warranty Information — Your seating system can be mounted onto the base in various forward and aft positions. Make certain that the We provide a manufacturer’s warranty for the product in accordance position selected provides you with maximum stability with our General Terms and Conditions of Business in the respective over the full range of seating positions. countries. — Consider all personal gear and accessories (backpacks, Warranty claims can only be made through the provider from whom vent systems, extra batteries, etc.) that will be carried on the product was obtained. the wheelchair. For example, a loaded backpack, attached to the back of the seating system, can 1.4 Safety Information on Using the Seating ... - Page 6 Driving and Seating are in operation. Limitations (LiNX System), page 8 ). — Power off power wheelchair immediatley to stop any — The wheelchair has a programmable controller which movement. allows adjustment of the maximum acceleration and deceleration of the wheelchair. Make sure that these are set to an appropriate level for the system and for you, the user. — When operating in reduced speed drive or anti-tipper lockout, always travel on a smooth level surface to ensure the wheelchair’s stability is not compromised. — Ensure all medical conditions are considered when setting up your wheelchair. Involuntary muscle movement such as spasms may affect the stability of the wheelchair, especially when the seating system is in a tilted or reclined position. — When a system is fully tilted or reclined, the front wheels of the wheelchair should never come off the ground. If this occurs, please contact your authorised Invacare dealer immediately to resolve the issue. 1656515-G...
-
Page 7: 2 Components
2 Components The telescopic seat frame is offered in different pre-assembled seat 2 Components heights (435 mm, 460 mm or 485 mm). Individual height adjustment can be made by the lifter, if the lifter is part of the configuration. A 2.1 Product Description manually height adjustment must be made by a qualified technician. For more information about height adjustment, refer to the service manual of the wheelchair. The following configurations may vary depending on country. 2.2 Power Positioning Functions The Modulite seating system is offered with different seat types. One Piece Seat Plate The seating system offers the following functions: The one piece seat plate is offered in different seat widths (380 mm or FIXED PIVOT TILT 430 mm). Individual width adjustment can be influenced by the choice At the fixed pivot tilt function the centre of gravity is shifted backward of the armrests. by the fixed pivot axis as the seat tilts back. Typical tilt range is 0° up to The one piece seat plate is offered in different seat depths (410 mm, 20°. 460 mm or 510 mm). The seat depth of the one piece seat plate can be CoG-TILT adjusted manually. Refer to 3.11.2 Adjusting Seat Depth, page 29. The CoG (centre of gravity) tilt function compensates for weight shift The one piece seat plate is offered in different pre-assembled seat by sliding the pivot axis and entire seat assembly forward as the seat heights (435 mm, 460 mm or 485 mm). A manually height adjustment tilts back. Typical tilt range is 0° up to 50°. For more information about must be made by a qualified technician. For more information about your specific configuration, refer to 8.1 Technical Specifications, page height adjustment, refer to the service manual of the wheelchair. -
Page 8: Manual Positioning Function
Modulite LEGRESTS 2.4 Driving and Seating Limitations (LiNX System) Our wide range of power and manual legrests are available in an array of sizes and styles including individual legrests and central foot DANGER! platforms to help secure and position clients’ legs. In addition, we offer Risk of Severe Injury or Death a multitude of legrest hangers to accommodate your legrest choice. Power legrests may be programmed to operate in one of the two The angle at which the limit switches/lockouts are set is following configurations: critical to the safe operation of the system. — Invacare will not be liable for any injuries or damage Individual (legrests operate independently), sustained when adjustments are made beyond the Combined (legrests operate in unison) factory recommended settings. 2.3 Manual Positioning Function — To ensure proper set-up, adjustments to lockouts and limits should only be performed by a qualified The seating system offers the following functions: technician. FIXED PIVOT TILT — Never exceed the maximum recommended limits. Lockouts and limit switches should be set up to best At the fixed pivot tilt function the centre of gravity is shifted backward meet the needs of the user without compromising the by the fixed pivot axis as the seat tilts back. Typical tilt range is 0° up to 15°. overall stability of the wheelchair. — Following any limit or lockout adjustments, always test RECLINE the seating system over the full range of motion (i.e. tilt, ... -
Page 9: Driving Limitations
2 Components For AVIVA RX and AVIVA FX, drive and seating restrictions are updated Limitation Cause for Limitation both while driving and while stationary. If lifter is raised 2.4.1 Driving Limitations Drive Slowdown / >50 mm Lockout adjustable by Seating systems are configured / programmed with a drive slowdown. and if backrest angle is provider The drive slowdown utilises microswitches to trigger the system into >130° – <140° reduced drive speed. If lifter is raised All tilt and recline seating systems are equipped with a drive lockout (DLO) limit to prevent the wheelchair from being driven when the >50 mm Drive Lockout seating system is tilted or reclined beyond a pre-determined safe total and if backrest angle is angle and / or a pre-determined height. The total angle can be any >140° combination of seat angle, backrest angle and / or surface angle. AVIVA RX with Lifter The provider can determine the angle when the drive slowdown should turn into a drive lockout. 130° AVIVA FX and TDX SP2 with Lifter 140° Limitation Cause for Limitation If lifter is raised Drive Slowdown... -
Page 10: Seating Limitations
Modulite AVIVA RX, AVIVA FX and TDX SP2 without Lifter There are no driving limitations for AVIVA RX, AVIVA FX and TDX SP2 without a lifter. 2.4.2 Seating Limitations AVIVA RX with Lifter 20° 0° Limitation Cause for Limitation If lifter is raised Tilting >20° inhibited >50 mm If tilt angle is Lifting inhibited >20° AVIVA FX and TDX SP2 with Lifter There are no seating limitations for AVIVA FX and TDX SP2 equipped with a lifter. AVIVA RX, AVIVA FX and TDX SP2 without Lifter There are no seating limitations for AVIVA RX, AVIVA FX and TDX SP2 without a lifter. 1656515-G... -
Page 11: 3 Setup
— Performance adjustments should only be made by a qualified technician. healthcare professionals or persons fully conversant — Adjustment by the user is only recommended after they with this process and the driver's capabilities. have been given appropriate guidance by the healthcare — After the power wheelchair has been set-up / adjusted, professional. check to make sure that the power wheelchair performs — DO NOT attempt to carry out the work if you do not to the specifications entered during the set-up have the listed tools available. procedure. If the power wheelchair does not perform to specifications, IMMEDIATELY turn the power wheelchair CAUTION! Off and re-enter set-up specifications. Contact Invacare, Risk of Injury or Damage if power wheelchair still does not perform to correct The power wheelchair is fitted with an individual, multiply specifications. adjustable seating system including adjustable legrests, armrests, a headrest or other options which are used to WARNING! adapt the seat to the physical requirements and the Risk of Death, Serious Injury or Damage condition of the user. It is possible that collisions or pinch Attaching hardware that is loosely secured or missing could points can occur between power wheelchair components cause instability resulting in death, serious personal injury, due to various combinations of adjustment options and their or property damage. -
Page 12: Adjusting Remote
Modulite When adapting the seating system and the seat functions to 3.2 Adjusting Remote the user: — Beware of pinch points when adjusting the power CAUTION! wheelchair components and Risk of the remote being pushed backwards during — ensure that no power wheelchair components collide. an accidental collision with an obstacle, such as a doorframe or table, and the joystick being jammed NOTICE! against the armpad if the position of the remote is The power wheelchair is manufactured and configured adjusted and all screws are not completely tightened individually to the specifications of the order. The This will cause the power wheelchair to drive forward assessment must be performed by a healthcare professional uncontrollably and potentially injure the power wheelchair according to the user´s requirements and health conditions. user and any person standing in the way. — Consult a healthcare professional if you intend to adapt — When adjusting the position of the remote, always make the power wheelchair configuration. sure to tighten all screws securely. — Any adaption should be performed by a qualified — If this should accidentally happen, immediately switch technican. ... -
Page 13: Adjusting Standard Remote Holder
3 Setup 3.2.1 Adjusting Standard Remote Holder 3.2.2 Adjusting Swing Away Remote Holder Adjusting Remote for Length of User's Arm Adjusting Remote Height 6 mm Allen key 1. Loosen wing screw A. 1. Loosen screw A. 2. ... -
Page 14: Adjusting Maxx Resolve Swing-Away Remote Holder
Modulite Adjusting Remote Position Height and Angle Adjustment The height / angle of the Maxx Resolve Remote Holder is adjusted via 3 mm Allen key two ball clamp assemblies on the swing away mechanism. The rear ball clamp assembly is attached to the remote tube, on the front ball clamp assembly the remote is mounted. Both ball clamp assemblies can be independently adjusted to position the remote at the height and / or angle that fits the user’s needs. 1. Loosen screws A. 2. Adjust component to desired position. 3. Tighten screws. ... -
Page 15: Adjusting Nucleus Midline Holder
3 Setup 5mm Allen key 6 mm Allen key 360° Angle Adjustment Height Adjustment 1. Use the cam wheel A to adjust the break-away tension to one of the four setting options: B hard C medium D easy E very easy 1. Loosen screws A in each ball clamp assembly. 2. Pivot / Rotate the ball clamp assemblies to desired angle / height. 3.3 Adjusting Nucleus Midline Holder 3. ... -
Page 16: Adjusting Depth Of Nucleus Midline Holder
Modulite Adjust it together with the armrest height. Refer to — Do not remove any small parts except to r eplace the corresponding armrest chapters, 3.8.1 Adjusting Armrest joystick knob. Height, page 21. — Do not leave removed joystick knob unattended. — Closely supervise children, pets or people with p hysical / Adjust the height of the nucleus midline holder only. Refer to mental disabilities. - Page 17 3 Setup Rotating Remote (DLX-REM110, DLX-REM2XX, DLX-REM400) DLX-REM500 3/16 inch (5 mm) Allen key 1. Loosen screw A. 2. Rotate remote in clamp to desired position. 3. ...
-
Page 18: Adjusting Swing-Away Mechanism
Modulite ASL Components on Nucleus Midline Holder Only CAUTION! Risk of Injury or Damage 5/32 inch (4 mm) Allen key Remaining burrs and missing end caps after m odifications on rods, such as shortened rod, can l ead to injury or damage. 1. Loosen screw A. ... -
Page 19: Adjusting Swing-Away Display Holder
3 Setup Adjusting Display Orientation 3.5 Adjusting Swing-Away Display Holder The display can be turned through 360 degrees. 3 mm Allen key 18 mm wrench Adjusting Holder Height 1. Loosen screws A. 2. Position holder to desired height. 3. ... -
Page 20: Adjusting Extremity Control Joystick
Modulite Adjusting Position on Holder CAUTION! Risk of Injury or Damage 5/32 inch (4 mm) Allen key Remaining burrs and missing end caps after m odifications on rods, such as shortened rod, can l ead to injury or damage. — Deburr cut after cutting excessive length. — Re-install end cap after deburring. 1. Loosen screws A. ... -
Page 21: Adjusting Head Array
3 Setup 3.7 Adjusting Head Array 3.8 Armrests Adjusting Pad Position 3.8.1 Adjusting Armrest Height Standard Armrest 5/32 inch (4 mm) Allen key 1. Loosen wing screw A. 2. Adjust component to desired 1. ... -
Page 22: Adjusting Armrest Width
Modulite Following Armrest 3.8.2 Adjusting Armrest Width 5 mm Allen key 8 mm Allen key 13 mm wrench Depending on the side, the screw is accessible from the front or the rear. 1. Remove screw A and nut B. 1. Loosen screw A. ... -
Page 23: Changing Resistance (Flip-Up / Following Armrest)
3 Setup 3.8.4 Changing Resistance (Flip-up / Following Armrest) 3.8.6 Adjusting Arm Pad Position (Flip-Up Armrest) The movement of the flip-up and following armrests can be set to have 5 mm Allen key greater or less resistance. 5 mm Allen key 1. Put component in vertical position. 2. ... -
Page 24: Adjusting Position Of Rea Headrest Or Neckrest
Modulite 4. Loosen the Allen screw D. It may be necessary to remove and modify the back 5. Slide the headrest left or right to the required position. cushion cover in order to access the headrest mounting 6. Re-tighten the Allen screw. holes on the back pan. An optional shim plate is available. It may be installed 3.9.2 Adjusting Height of Rea Headrest or Neckrest between the clamp assembly and the back pan to provide The adjustment of the height is the same for all Rea headrests and additional spacing / clearance on Posture Back and Deep neckrests. Back. The headrest clamp hardware is designed to install into existing mounting holes in the backrest pan. 1. Loosen hand screw A. ... -
Page 25: Adjusting Elan Headrest Hardware
3 Setup Installing 3.9.4 Adjusting Elan Headrest Hardware 2.5 mm Allen key Elan headrest hardware is highly adjustable. The illustration below shows the possible adjustment ranges of the joints. 4 mm Allen key 5 mm Allen key 1. Using hardware provided, align and install headrest clamp assembly into existing mounting holes in backrest pan A. 2. Install headrest pad (not shown) to headrest rod using mounting hardware provided. The headrest pad can be ... -
Page 26: Adjusting Backrest
Modulite Adjusting Depth and Angle 3.10.1 Adjusting Backrest Height The headrest can be further adjusted for depth and angle via the articulating hardware. The following section describes the procedures for adjusting the height of the backrest plate. 4 mm Allen key The sling back is only available in fixed heights of 48 and 54 cm. 5 mm Allen key 5 mm Allen key 1. Loosen screws and clamping levers of dual link adjustment assembly A and screws of upper and lower rotational pivots B. ... -
Page 27: Adjusting Backrest Angle
3 Setup The sling back is only available in two widths of 38-43 cm and 3.10.3 Adjusting Backrest Angle 48-53 cm and, under certain circumstances, must be replaced for a width adjustment. For a replacement description, see the CAUTION! service manual for this power wheelchair. The service manual can be ordered from Invacare. However, they contain Every change to the seat angle and the backrest instructions for specially trained service technicians and angle alters the geometry of the power wheelchair describe operations that are not intended for the end user. and affects its dynamic stability Note that if the sling back width is adjusted the backrest — For more information on stability, overcoming obstacles cushion must also be replaced. correctly, driving along inclines and slopes and the correct position of the backrest and seat angles, see the 5 mm Allen key user manual of the power wheelchair. CAUTION! Risk of falling out of the wheelchair 1. Loosen and remove screw A. ... -
Page 28: Adjusting Tension Adjustable Backrest Upholstery
Modulite Width-Adjustable Backrest 3.10.4 Adjusting Tension Adjustable Backrest Upholstery 6 mm Allen key 1. Remove upper backrest screw Remove backrest cushion A on both sides. ... -
Page 29: Adjusting Seat Depth
3 Setup The description of how the width is adjusted is contained in the service manual for this power wheelchair. The service manual can be ordered 6 mm Allen key from Invacare. However, they contain instructions for specially trained service technicians and describe operations that are not intended for 1. Loosen bottom backrest screws A on the end user. both sides. 3.11.2 Adjusting Seat Depth Do not remove screws A. The seat depth has a major influence on the selection of the 2. Adjust component to desired position. centre of gravity of the seat. This impacts its dynamic stability. You can adjust seat depth steplessly. If you make a major change to the seat depth the centre of Use scale B on seat as a guide. gravity of the seat must also be adjusted. See "Adjusting the Ensure that same seat depth is set on centre of gravity of the seat" in the service manual for this both sides. ... -
Page 30: Adjusting Lateral Trunk Support
Modulite Adjusting Height It is easier to adjust the angle of the seat when there is nobody sitting in the wheelchair. 5 mm Allen key 1. Loosen screws A. 2. Adjust component to desired position. 3. Tighten screws. Adjusting Depth 5 mm Allen key The figure shows the position of the spindle A for manual seat angle adjustment. 1. Loosen screws A. 2. Adjust component to desired 3.12 Adjusting Lateral Trunk Support position. 3. Tighten screws. Adjusting Width 1. Loosen knobs A. 2. Adjust component to desired position. 3. Tighten knobs. 1656515-G... -
Page 31: Adjusting Hip Support With Quick Release
3 Setup Adjusting Angle 3.13 Adjusting Hip Support with Quick Release 5 mm Allen key Adjusting Position 5 mm Allen key 1. Loosen screws A. 2. ... -
Page 32: Adjusting / Removing Tray
Modulite Via bracket Adjusting Hip Pad Height You can adjust the hip pad height in two ways: 5 mm Allen key Via its mounting slots. Via its bracket. Via mounting slots 10 mm wrench Remove upper screw and friction cap A. 2. Remove small friction link B. ... -
Page 33: Adjusting Tray Laterally
3 Setup a vehicle and cause damage or injury t o users in the event of 3.14.2 Adjusting Depth of Tray / Removing Tray a collision. — When possible, other auxiliary power wheelchair equipment should be either secured to the p ower wheelchair or removed from the power wheelchair and 1. Loosen wing screw A. secured in the vehicle during travel. -
Page 34: Setting Angle Of Legrest
Modulite 1. Hold the legrest securely. 2. Pull the lever A. Remove removable axle A. 3. Push the legrest into the required position. ... -
Page 35: Setting Angle Of Footplate
3 Setup 3.15.4 Setting Angle of Footplate 3.16 LNX Legrest 3.16.1 Setting Length of Legrest 5/32 inch (4 mm) Allen key If needed, the legrest can be pre-set to 83° or 97° instead of 90°. Contact your Invacare provider. 4 mm Allen key 10 mm open-ended wrench You can adjust the length of the legrests independently of one another. 1. Fold the footplates up in order to access the adjusting screws A. 2. Set the adjusting screws. ... -
Page 36: Setting Angle Of Footplate
Modulite The legrest with foot platform is adjusted the same way. Set spacers on the inside to increase width. Set spacers on the outside to decrease width. Each spacer increases or decreases the width by 1/4” (6.35 mm). 6 mm Allen key 1. Remove screw A. 2. Remove spacers B and footplate. ... -
Page 37: Adjusting Calf Pads
3 Setup 3. Adjust the calf pad to the required height and width. 3.16.5 Adjusting Calf Pads 4. Re-tighten the bolts. 5. Fold the calf pad back. Risk of damage to the power wheelchair —... -
Page 38: Setting Angle
Modulite 3.17.2 Setting Angle CAUTION! Risk of injury due to incorrect adjustment of the footrests and legrests Loosen the screw C. — Before and during every journey it is imperative t o ensure that the footrests contact neither the c astor wheels nor the ground. 6 mm Allen key 4. Set the desired angle. ... - Page 39 3 Setup 6. Re-tighten the counternut. The rubber stop can be screwed in or out B or pushed up or down C. Move the legrest to the desired position. Loosen the screw D and swivel the 8. Re-tighten the screw. legrest upward in order to access the rubber stop. Loosen the counternut E. Move the rubber stop to the desired position. 1656515-G...
-
Page 40: Adjusting Length Of Legrest
Modulite 3.17.4 Adjusting Length of Legrest CAUTION! 1. Press the unlocking button A and Risk of injury due to incorrect adjustment of the swivel the legrest outward. footrests and legrests 2. Remove the legrest in an upward — Before and during every journey it is imperative t o direction. ensure that the footrests contact neither the c astor wheels nor the ground. 5 mm Allen key 3.18.2 Setting Angle CAUTION! Risk of injury due to incorrect adjustment of the ... -
Page 41: Setting End Stop Of Legrest
3 Setup 3.18.3 Setting End Stop of Legrest 10 mm wrench Hit the knob to release the locking mechanism. The end position of the legrest is determined by means of a rubber stop The rubber stop can be screwed in or out B or pushed up or down C. Set the desired angle. Loosen the locking knob D counter- clockwise at least one turn. Turn the knob clockwise to tighten it. 1656515-G... - Page 42 Modulite Move the rubber stop to the desired position. Hit the knob to release the locking mechanism. 8. Re-tighten the counternut. Move the legrest to the desired position. Swivel the legrest upward in order to access the rubber stop. 10. Re-tighten the locking knob. Use the wrench to loosen the counternut E. 1656515-G...
-
Page 43: Adjusting Length Of Legrest
3 Setup 3.18.4 Adjusting Length of Legrest 3.18.5 Adjusting Calf Pads Adjusting Height CAUTION! Risk of injury due to incorrect adjustment of the 4 mm Allen key footrests and legrests — Before and during every journey it is imperative t o ensure that the footrests contact neither the c astor wheels nor the ground. 1. Loosen the screws A. 2. Adjust to the desired position. ... -
Page 44: Adjusting Footrests
Modulite Unlocking and Swivelling Calf Pad Backward 3.18.6 Adjusting Footrests Adjusting Angle–adjustable Footrests 5 mm Allen key Press t he calf pad straight down. 1. Loosen both set screws on the footrest. 2. Adjust to the desired angle. 3. Re-tighten the screws. ... -
Page 45: Adm Legrests
3 Setup CAUTION! 3.19 ADM Legrests Risk of crushing — Do not reach inside the swivelling range of the l egrest. 3.19.1 Swivelling Legrest Outward and / or Removing The small unlocking button is located on the upper section of the Raising legrest. When the legrest is unlocked, it can be swivelled inward or outward when getting into the wheelchair as well as being removed completely. 1. Pull the legrest upward until the 1. Press the unlocking button A and desired angle has been achieved. swivel the legrest outward. 2. Remove the legrest in an upward direction. Lowering 3.19.2 Setting Angle CAUTION! 1. ... -
Page 46: Adjusting Length Of Legrest
Modulite 3.19.3 Adjusting Length of Legrest 3.19.4 Adjusting Calf Pads Adjusting Height CAUTION! Risk of injury due to incorrect adjustment of the 4 mm Allen key footrests and legrests — Before and during every journey it is imperative t o ensure that the footrests contact neither the c astor wheels nor the ground. 1. Loosen the screws A. 2. Adjust to the desired position. ... -
Page 47: Adjusting Footrests
3 Setup Unlocking and Swivelling Calf Pad Backward 3.19.5 Adjusting Footrests Adjusting Angle–adjustable Footrests 5 mm Allen key Press t he calf pad straight down. 1. Loosen both set screws on the footrest. 2. Adjust to the desired angle. 3. ... -
Page 48: Powered Elevating Legrests (Ade Legrests)
Modulite CAUTION! 3.20 P owered Elevating Legrests (ADE Legrests) Risk of injury due to incorrect adjustment of the footrests and legrests 3.20.1 Swivelling Legrest Outward and / or Removing — Before and during every journey it is imperative t o The small unlocking button is located on the upper section of the ensure that the footrests contact neither the c astor legrest. When the legrest is unlocked, it can be swivelled inward or wheels nor the ground. outward when getting into wheelchair as well as being removed completely. The electrically height-adjustable legrests are operated using the remote. Refer to the separate user manual for your remote for more ... -
Page 49: Adjusting Calf Pads
3 Setup Unlocking and Swivelling Calf Pad Backward 3.20.4 Adjusting Calf Pads Adjusting Height 4 mm Allen key Press t he calf pad straight down. 1. Loosen the screws A. 2. Adjust to the desired position. 3. Re-tighten the screws. Adjusting Depth The depth of the calf pad can be adjusted via the holding plate. ... -
Page 50: Adjusting Footrests
Modulite 3.20.5 Adjusting Footrests 3.21 Adjusting Standard 80° Legrest Adjusting Angle–adjustable Footrests Swivelling and / or Removing 5 mm Allen key 1. Push release lever A inward or 1. Loosen both set screws on the outward. footrest. ... -
Page 51: 4 Usage
4 Usage 4 Usage 4.2 Removing / Inserting Hip Support with Quick Release 4.1 Removing Armrest for Side Transfer Flip-up Armrest Removing Hip Support 1. Pull lever A upwards. 2. ... -
Page 52: Replacing Backrest Cushion
Modulite Installing Backrest Cushion 4.3 Replacing Backrest Cushion only for Matrx Elite backrests Removing Backrest Cushion 1. Attach hook and loop strip at 2. Fold cushion upwards. the lower backrest. 1. Loosen hook and loop strip 2. Lift cushion upwards. at the lower backrest. 3. Attach hook and loop strip at backrest handle. 3. Loosen hook and loop strip at backrest handle. 1656515-G... -
Page 53: Using Lnx Powered Central Legrest With Telescoping Footboard
4 Usage 4.4 Using LNX Powered Central Legrest with Telescoping Footboard Adjusting Angle WARNING! Pinch point Risk of pinching when adjusting legrest angle. — Keep top of legrest clear when adjusting legrest angle. Lowering Footboard NOTICE! Lowering footboard until preset point could damage floor. — Stop lowering footboard when it touches the floor. You can lower the telescoping footboard until a preset point. Depending on the wheelchair configuration, this point might not exactly fit the seat-to-floor height but end a few millimeters above or push a few millimeters into the floor. Drive Lockout NOTICE! Driving the wheelchair with lowered footboard could damage the legrest. — As soon as you move the footboard, a drive lockout engages. 1. To disengage drive lockout, retract footboard to top position. 1656515-G... -
Page 54: 5 Maintenance Schedule
Modulite 5 Maintenance Schedule Charge batteries (refer to your wheelchair’s user manual for important information on battery charging and proper battery To ensure the optimal safety and reliability of your power positioning care). system, adhere to the maintenance schedule / table below. In addition Monthly Inspection Checklist: t o the maintenance schedule, note the following maintenance tasks and safety warnings that should be incorporated into your daily Electrical / Wiring harnesses: routine. Check for pinches or pulls in wiring (over full range of seating s ystem) WARNING! Inspect for wear & tear damage to wires Any sudden or gradual deterioration in t he function ... -
Page 55: 6 After Use
6 After Use 6 After Use 6.1 Reconditioning This product is suitable for reuse. To recondition the product for a new user, carry out the following actions: Inspection Cleaning and disinfection Adaptation to the new user For detailed information, see and the service manual for this product. Make sure that the user manual is handed over with the product. If any damage or malfunction is detected, do not reuse the product. 6.2 Disposal Be environmentally responsible and recycle this product through your recycling facility at its end of life. Disassemble the product and its components, so the different materials can be separated and recycled individually. The disposal and recycling of used products and packaging must comply with the laws and regulations for waste handling in each country. Contact your local waste management company for information. 1656515-G... -
Page 56: 7 Troubleshooting
7 Troubleshooting 7 Troubleshooting 7.1 Performance Troubleshooting For additional troubleshooting information regarding the power wheelchair & electronics, refer to the Troubleshooting section of the power wheelchair and remote user manuals (provided separately). Symptom Probable Cause Solutions System tilted and / or elevated beyond Return seating system to neutral (home) the drive lockout (DLO) angle position. Wheelchair power is ON, but system does not Drive motors not engaged Engage drive motors. drive LNX powered central legrest with Retract footboard to top position. telescoping footboard lowered Check / charge / replace batteries. Low batteries Contact your provider. Check cable connections / check cable ties (too Loose/faulty electrical connection tight / too loose). Contact your provider. Seating system not functioning Inspect / replace fuse. Blown fuse Contact your provider. Check for sources of interference or Interference / obstructions, pinched obstructions / inspect cables for pinch points. wires Contact your provider. 1656515-G... - Page 57 Modulite Symptom Probable Cause Solutions Check cable connections / check cable ties (too Loose / faulty electrical connection tight / too loose). Check / replace power harness. Faulty power harness Contact your provider. Intermittent seating system functions (day to day, during tilt, during recline...) Check / replace limit switch. Faulty limit switch Contact your provider. Nearly exhausted battery (fluctuating Check / replace battery. charge) Contact your provider. Check connections. Loose / faulty electrical connection Contact your provider. Drive lockout (DLO) is not functioning DLO limit switch / mechanical switch is Contact your provider. not set properly Faulty DLO limit switch Contact your provider. Check connections. Loose / faulty electrical connection Contact your provider. Limit switch not functioning properly Check/ replace limit switch. Faulty limit switch Contact your provider. Limit switch is not set–up properly Contact your provider. 1656515-G...
- Page 58 7 Troubleshooting Symptom Probable Cause Solutions Limit is exceeded (DLO, RDS, back angle, Come within limit ranges. elevating seat lockout) Check / replace limit switch. Faulty limit switch Contact your provider. System only operates in one direction Limit switch is not set–up properly Contact your provider. Low voltage Contact your provider. Battery not charged Charge batteries. Remote not plugged in Inspect cable connection. Turn on power to the remote via the keypad. Remote will not function Remote not turned on Contact your provider. Blown base fuse Inspect / replace fuse. Inspect / adjust harness position to prevent Actuator keeps running Pinched switch harness pinching. Contact your provider. 1656515-G...
-
Page 59: 8 Technical Data
8 Technical Data 8 Technical Data 8.1 Technical Specifications The technical information provided hereafter applies to a standard configuration or represents maximum achievable values. These can change if accessories are added. The precise changes to these values are detailed in the sections for the respective accessories. Note that in some cases the measured values may vary up to ± 10 mm. For more technical data of the power wheelchair see the user manual of your wheelchair. Dimensions and Weights of Modulite Seating System Dimensions According Power W heelchair to ISO 7176-5 TDX S P2 (Standard) AVIVA RX (Standard) AVIVA R X (HD) AVIVA F X ... - Page 60 Modulite Dimensions According Power W heelchair to ISO 7176-5 TDX S P2 (Standard) AVIVA RX (Standard) AVIVA R X (HD) AVIVA F X Armrest Height Telescopic Seat Frame [mm] 245 – 310 / 295 – 360 T-Armrest ...
- Page 61 8 Technical Data Dimensions According Power W heelchair to ISO 7176-5 TDX S P2 (Standard) AVIVA RX (Standard) AVIVA R X (HD) AVIVA F X 0° ... +20° ...
- Page 62 Notes...
- Page 63 Notes...
