Block Programming Instructions

3-32-6 ONE CYCLE AND WAIT (NOT): WAIT(805)/WAIT(805) NOT

Purpose
Ladder Symbol
Variations
Applicable Program Areas
Operand Specifications
Stops execution of the rest of the block program until an execution condition
turns ON or an operand bit turns ON or OFF.
WAIT(805)
WAIT(805)
WAIT(805) NOT
Variations Always Executed in Block Program
Block program areas
OK
Note WAIT(805)/WAIT(805) NOT must be used in block programming regions even
within subroutines and interrupt tasks.
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
Task Flags
Condition Flags
Clock Pulses
CIO 000001 ON
0
Block ended
CIO 000003 and CIO 000003 or
CIO 000004 ON
2
Block ended
B: Bit operand
B
B
Step program areas
OK
CIO 000000 to CIO 614315
W00000 to W51115
H00000 to H51115
A00000 to A44715
A44800 to A95915
T0000 to T4095
C0000 to C4095
TK0000 to TK0031
ER, CY, >, =, <, N, OF, UF, >=, <>, <=ON, OFF, AER
0.02 s, 0.1 s, 0.2 s, 1 s, 1 min
Section 3-32
CIO 000001 OFF
CIO 000004 OFF
Subroutines Interrupt tasks
OK OK
B
