Failure Diagnosis Instructions
Operand Specifications
1142
Generating or Clearing User-defined Non-fatal Errors
The following table shows the function of the operands.
Note The value of operand N must be different from the content of A529
(the system-generated FAL/FALS number).
N
0
1 to 511
(These FAL num-
bers are shared
with FALS num-
bers.)
Note *Other settings would be constants #0200 through #FFFE or a word address.
Generating Non-fatal System Errors (CS1-H, CJ1-H, CJ1M, or CS1D Only)
The following table shows the function of the operands.
Note The value of operand N must be the same as the content of A529
(the system-generated FAL/FALS number).
Operand
N 1 to 511 (These FAL numbers are shared with FALS numbers.)
S Error code that will be generated. (See Description below.)
S+1 Error details code that will be generated. (See Description below.)
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
S
#0001 to #01FF Clears the non-fatal error with the correspond-
ing FAL number.
#FFFF Clears all non-fatal errors.
Other* Clears the most serious non-fatal error.
#0000 to #FFFF Generates a non-fatal error with the corre-
sponding FAL number (no message).
Word address Generates a non-fatal error with the corre-
sponding FAL number.
The 16-character ASCII message contained in
S through S+7 will be displayed on the Pro-
gramming Device.
Function
N
---
---
---
---
---
---
---
---
---
---
---
0 to 511
---
Section 3-30
Function
S
CIO 0000 to CIO 6143
W000 to W511
H000 to H511
A000 to A959
T0000 to T4095
C0000 to C4095
D00000 to D32767
E00000 to E32767
En_00000 to En_32767
(n = 0 to C)
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
#0000 to #FFFF
(binary)
