Block Programming Instructions

3-32-2 BLOCK PROGRAM BEGIN/END: BPRG(096)/BEND(801)

Purpose
Ladder Symbols
Variations
Applicable Program Areas
Operands
Operand Specifications
(BPRG(096))
1192
Define a block programming area. For every BPRG(096) there must be a cor-
responding BEND(801).
BLOCK PROGRAM BEGIN
BPRG(096)
N
BLOCK PROGRAM END
BEND(801)
BPRG(096)
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation Not supported.
Immediate Refreshing Specification
BEND(801)
Variations
Block program areas
(See note.)
Note BPRG(096) is allowed only once at the beginning of each block program.
N: Block Program Number
The block program number must be between 0 and 127 decimal.
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
EM Area without bank
EM Area with bank
Indirect DM/EM
addresses in binary
Indirect DM/EM
addresses in BCD
Constants
Data Registers
Index Registers
Indirect addressing
using Index Registers
N: Block program number
Always Executed in Block Program
Step program areas Subroutines
OK OK
---
---
---
---
---
---
---
---
---
---
---
0 to 127 (decimal)
---
---
---
Section 3-32
BPRG(096)
Not supported.
Not supported.
Interrupt tasks
OK
N
