Installing and Uninstalling the Software
Installing FinsGateway
Step 1: Backing Up the
FinsGateway Settings
1, 2, 3...
Step 2: Removing the
Previous FinsGateway
Step 3: System Restart
Step 4: Internet Explorer
Installation
Step 5: Updating
ComCtl32.dll
Step 6: Updating the
HTML Help Runtime
Component
1, 2, 3...
• If FinsGateway is being installed for the first time, start the procedure from Step
4: Internet Explorer Installation.
If necessary, back up the previous FinsGateway settings, as follows:
Note If FinsGateway is removed (uninstalled) without backing up the setting data, the
previous setting data will all be lost.
1. Execute the Backup/Restore FinsGateway Setting Data program on the
CD.
<CD-ROM drive>:\Fgwv3\FgwUtils\SettingSalvage.exe
2. Select the Backup to File option, and click OK.
Remove the previous version of FinsGateway by referring to that manual for de-
tails.
Note If the FinsGateway reinstallation process fails, execute the following program
from the CD-ROM to remove all the files and registry data used by FinsGateway.
<CD–ROM drive>:\Fgwv3\FgwUtils\FgwRemover3.exe
After removing FinsGateway, restart the computer. If the following steps are per-
formed without restarting the computer, the installation will not be completed
properly.
If Internet Explorer is not already installed, or if the version is old, the FinsGate-
way installation will display a warning to update it. Update Internet Explorer.
Microsoft Internet Explorer is not included on the CD-ROM. Refer to the
Microsoft website for details, and install the newest version.
If the program is not correctly displayed or does not operate correctly when using
Windows NT 4.0, then update the ComCtl32.dll file. This is not necessary when
using Windows 2000, XP, Vista, or 7.
Use 401comupd.exe to update the ComCtl32.dll file. The 401comupd.exe file is
an update program provided by Microsoft Corporation.
If the HTML Help runtime component is not already installed, or if the version is
old, the FinsGateway installation will display a warning to update it. Update the
HTML Help runtime component as follows:
1. Execute the following program from the CD-ROM:
<CD-ROM drive>:\Fgwv3\Update\hhupd.exe
2. Update the HTML Help runtime component according to the instructions
displayed on the screen.
3. The program will suggest a system restart when it finishes.
Do not proceed to the next step without restarting the computer. If the instal-
