Function Blocks/ITEMs Incompatible with Earlier Versions
1-5-3 Incompatibility with Versions Earlier than Version 2.00
26
uploaded to CX-Process Tool, only the following function blocks are not
uploaded. (When a new upload is performed, these blocks become empty.)
Segment Program 2 (Block Model 157), Accumulated Value Input Adder
(Block Model 182), Accumulated Value Input Multiplier (Block Model
183), Constant Comparator (Block Model 202), Variable Comparator
(Block Model 203), Clock Pulse (Block Model 207), ON/OFF Valve Ma-
nipulator (Block Model 221), Motor Manipulator (Block Model 222), Re-
versible Motor Manipulator (Block Model 223), Motor Opening Manipula-
tor (Block Model 224)
Likewise, the following functions can be used only when Loop Control Unit
CS1W-LC001 Ver.1.50 and onwards and CX-Process Tool Ver.1.50 and on-
wards are used:
• The following ITEMs can be set on CX-Process Tool when versions of Loop
Control Unit earlier than Ver.1.50 (Ver.1.0jN or Ver.1.20) and CX-Process
Tool Ver.1.50 or onwards are used. However, if the data of these ITEMs is
downloaded to the Loop Control Unit when these ITEMs are set on CX-Pro-
cess Tool, only those ITEMs are not downloaded. (Other ITEMs are down-
loaded successfully.)
• The following ITEMs cannot be set on CX-Process Tool when Loop Control
Unit Ver.1.50 or onwards and versions of CX-Process Tool lower than Ver.1.50
(Ver.1.00 or Ver. 1.20) are used. For this reason, these ITEMs cannot also be
downloaded to the Loop Control Unit. If a download in major item units (Loop
Control Units) or a download in function blocks units including initial setting
data is performed, the respective defaults are set to the following ITEMs on the
Loop Control Unit. If the following ITEMs are already set on the Loop Control
Unit and are uploaded to the CX-Process Tool, only the following ITEMs are
not uploaded.
AT (auto-tuning) functions of Basic PID block (Block Model 011) and Ad-
vanced PID (Block Model 012), and wait function and additional steps
(step numbers 8 to 15) of the Ramp Program block (Block Model 155)
Note 1. For details on which actual ITEM this restriction applies to, refer to the ITEM
list for the relevant function block in the Function Block Reference Manual.
2. The version of the Loop Control Unit can be verified in the Monitor Run Sta-
tus Screen (Execution, Operation, Monitor Run Status) on CX-Process
Tool.
When the above function blocks are used, check in the Check System Op-
eration screen on CX-Process Tool beforehand that the content of ITEM 099
onwards in the System Common block (Block Model 000) is as follows:
ITEM
099
The following function blocks described in this manual can be used only when
Loop Control Unit CS1W-LC001 Ver. 2.00 and onwards and CX-Process Tool
Ver. 2.00 and onwards are used:
• The following function blocks can be registered on CX-Process Tool when ver-
sions of Loop Control Unit earlier than Ver. 2.00 (Ver. 1.0j, Ver. 1.20, or Ver.
1.50) and CX-Process Tool Ver 1.50 or onwards are used. However, if the data
of these function blocks is downloaded to the Loop Control Unit in major item
units (units of Loop Control Unit) when these function blocks are registered on
Data name
MPU/FROM version indication V1.50
Version V1.50 and onwards must be indicated.
Section 1-5
Data
