Programming Concepts
Data Operand
16-bit con- All binary data or
stant a limited range of
binary data
All BCD data or a
limited range of
BCD data
32-bit con- All binary data or
stant a limited range of
binary data
All BCD data or a
limited range of
BCD data
Data form Symbol
Unsigned binary #
Signed decimal ±
Unsigned deci- &
mal
BCD #
Unsigned binary #
Signed binary +
Unsigned deci- & (See Note.)
mal
BCD #
Range Application example
#0000 to #FFFF
MOV(021)
#5A
D100
–32768 to
+(400)
+32767
D200
D300
&0 to &65535
CMP(020)
D400
&999
#0000 to #9999
B(414)
D500
#2000
D600
#00000000 to
MOVL(498)
#FFFFFFFF
#17FFF
D100
–2147483648 to
+L(401)
+2147483647
D200
65536
D300
&0 to
CMPL(060)
&429467295
D400
&99999
#00000000 to
BL(415)
#99999999
D500
#1000000
D600
