Data Movement Instructions
3-7-12 SINGLE WORD DISTRIBUTE: DIST(080)
Purpose
Ladder Symbol
Variations
Applicable Program Areas
Operands
Operand Specifications
Transfers the source word to a destination word calculated by adding an offset
value to the base address.
DIST(080)
S: Source word
S
Bs: Destination base address
Bs
Of Of: Offset
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation Not supported
Immediate Refreshing Specification
Block program areas
OK OK
Bs: Destination Base Address
Specifies the destination base address. The offset is added to this address to
calculate the destination word.
Of: Offset
This value is added to the base address to calculate the destination word. The
offset can be any value from 0000 to FFFF (0 to 65,535 decimal), but Bs and
Bs+Of must be in the same data area.
15
Bs
to
to
Bs+Of
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
Indirect DM addresses
in binary
Indirect DM addresses
in BCD
Constants
Data Registers
Step program areas Subroutines
OK
0
S
CIO 0 to CIO 6143
W0 to W511
H0 to H511
A0 to A959 A448 to A959
T0000 to T4095
C0000 to C4095
D0 to D32767
@ D0 to @ D32767
*D0 to *D32767
#0000 to #FFFF ---
(binary)
DR0 to DR15 ---
Section 3-7
DIST(080)
@DIST(080)
Not supported
Interrupt tasks
OK
Bs Of
A0 to A959
#0000 to #FFFF
(binary) or &0 to
&65535
DR0 to DR15
267
