Display Instructions
Example
Numeric Values Corresponding to 7-segment Displays
0 (3F) 1 (06)
A (77) B (7C)
K (72 ) L (38)
U (3E) V (1C)
When W0.02 turns ON in the following example, the individual segments of
the 7-segment display on the CPU Unit will be controlled according to the con-
tents of D200 (7678 ="Ht"). The display remains even when W0.02 turns OFF.
When W0.03 turns ON, the display is cleared.
W0.02
W0.03
Left digit
Bit 13
Bit 14
Bit 12
Bit 11
Bit 15 14 13
Status 0 1
7
2 (5B) 3 (4F) 4 (66)
C (39) D (5E) E (79)
M (5 5) N (54) O (5C)
W (6A) X (1D) Y (6E)
SCTRL(048)
D200
SCTRL(048)
#0000
Bit 8
Bit 9
Bit 10
Bit 15
12 11 10 09 08
1 1 0 1 1 0
6
5 (6D) 6 (7D)
F (71) G (3D)
P (73) Q (67)
Z (49)
Section 3-25
Display data
D200
7 6 7 8
"H" "t"
Display cleared.
Right digit
Bit 5
Bit 6
Bit 4
Bit 3
Bit 07 06 05 04 03
Status 0 1 1 1 1
7
7 (27) 8 (7F)
H (76 ) I (19 )
R (50) S (6D)
Bit 0
Bit 1
Bit 2
Bit 7
02 01 00
0 0 0
8
9 (6F)
J (0D )
T (78)
