Omron CP - PROGRAMMING MANUAL 05-2007 Programming Manual page 932

Network Instructions
Operand Specifications
Description
Flags
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
Indirect DM addresses in
binary
Indirect DM addresses in BCD *D0 to *D32767
Constants
Data Registers
Index Registers
Indirect addressing using
Index Registers
Sends the explicit message command with service code 10 hex (stored in the
range of words beginning at S+2) to the node address specified in S+1, via
the Communications Unit with the FINS unit address specified in bits 00 to 07
of C. When the response to the explicit message is received, it is stored in the
range of words beginning at D+2.
The setting in bits 12 to 15 of C (0 or 8 hex) determines the byte-order of the
service data stored at S+5.
• Storing Data from the Leftmost Byte
Set bits 12 to 15 of C to 0 hex.
Frame (order of data in line)
A B
Data
Stored from leftmost byte.
area
15
S+5 A
S+6 C
Note: A, B, C, and D represent bytes of data.
• Storing Data from the Rightmost Byte
Set bits 12 to 15 of C to 8 hex.
Frame (order of data in line)
A B
Data
area
15
S+5 B
S+6 D
Note: A, B, C, and D represent bytes of data.
Name Label
Error Flag ER
S
CIO 0 to CIO 6143
W0 to W511
H0 to H511
A0 to A959
T0000 to T4095
C0000 to C4095
D0 to D32767
@ D0 to @ D32767
---
---
---
,IR0 to ,IR15
–2048 to +2047, IR0 to –2048 to +2047, IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
C D
08 07 00
B
D
C D
Stored from rightmost byte.
08 07 00
A
C
Operation
ON if the Communications Port Enabled Flag is OFF for
the communications port number specified in C.
OFF in all other cases.
Section 3-24
C
CIO 0 to CIO 6141
W0 to W509
H0 to H509
A0 to A957
T0000 to T4093
C0000 to C4093
D0 to D32765
899
