High-speed Counter/Pulse Output Instructions
3-20-7 PULSE OUTPUT: PLS2(887)
Purpose
Ladder Symbol
Variations
Applicable Program Areas
Operands
PLS2(887) outputs a specified number of pulses to the specified port. Pulse
output starts at a specified startup frequency, accelerates to the target fre-
quency at a specified acceleration rate, decelerates at the specified decelera-
tion rate, and stops at approximately the same frequency as the startup
frequency. Only independent mode positioning is supported.
PLS2(887) can also be executed during pulse output to change the number of
output pulses, target frequency, acceleration rate, or deceleration rate.
PLS2(887) can thus be used for sloped speed changes with different acceler-
ation and deceleration rates, target position changes, target and speed
changes, or direction changes.
PLS2(887)
P
M P: Port specifier
M: Output mode
S
S: First word of settings table
F
F: First word of starting frequency
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation Not supported
Immediate Refreshing Specification
Block program areas
OK OK
P: Port Specifier
The port specifier indicates the port.
P
0000 hex Pulse output 0
0001 hex Pulse output 1
0002 hex Pulse output 2 (CP1H only)
0003 hex Pulse output 3 (CP1H only)
0020 hex Inverter positioning 0 (CP1L only)
0021 hex Inverter positioning 1 (CP1L only)
M: Output Mode
The content of M specifies the parameters for the pulse output as follows:
Step program areas Subroutines
OK
Port
Section 3-20
PLS2(887)
@PLS2(887)
Not supported
Interrupt tasks
OK
731
