Omron CP - PROGRAMMING MANUAL 05-2007 Programming Manual page 937

Network Instructions
Applicable Program Areas
Operands
Operand Specifications
904
Block program areas
OK OK
S: First Source Word in Remote CPU Unit
Specifies the leading word address containing the data to be read from the
remote CPU Unit.
D: First Destination Word in Local CPU Unit
Specifies the leading word address where the read data will be stored in the
local CPU Unit.
C: First Control Word
Specifies the first of five control words (C to C+4).
15 12 11 8 7
C 0 0
15 12 11 8 7
C+1 0 0
15 12 11 8 7
C+2 0
FINS unit address of relaying Communications Unit.
CPU Bus Unit: 10 to 1F hex (unit number + 10 hex)
Special I/O Unit: 20 to 7F hex (unit number + 20 hex)
Port number of the communications port
(logical port) for the network instruction:
0 to 7 hex (F hex: Automatic allocation)
15
C+3
Response monitoring time
0001 to FFFF hex (0.1 to 6553.5 s)
0000 hex: 2 s (default setting)
15
C+4
Explicit message format
0000 hex: DeviceNet
(same as using the 2801 FINS command)
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
Indirect DM addresses in
binary
Indirect DM addresses in
BCD
Constants
Step program areas Subroutines
OK
0
Source node address (remote CPU Unit)
(00 to maximum node address (hex))
Example: DeviceNet: 00 to 3F hex (0 to 63)
0
Read data size (words):
01 to 64 hex (1 to 100 words)
0
0
0
S
CIO 0 to CIO 6143
W0 to W511
H0 to H511
A0 to A959 A448 to A959
T0000 to T4095
C0000 to C4095
D0 to D32767
@ D0 to @ D32767
*D0 to *D32767
---
Section 3-24
Interrupt tasks
OK
D C
CIO 0 to CIO 6139
W0 to W507
H0 to H507
A0 to A955
T0000 to T4091
C0000 to C4091
D0 to D32763
