Conversion Instructions
3-11-8 DATA DECODER: MLPX(076)
Purpose
Ladder Symbol
Variations
Applicable Program Areas
Operands
Operand Specifications
400
Reads the numerical value in the specified digit (or byte) in the source word,
turns ON the corresponding bit in the result word (or 16-word range), and
turns OFF all other bits in the result word (or 16-word range).
MLPX(076)
S
C
R
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation Not supported
Immediate Refreshing Specification
Block program areas
OK OK
S: Source Word
The data in the source word indicates the location of the bit(s) that will be
turned ON.
C: Control Word
The control word specifies whether MLPX(076) will perform a 4-to-16 bit con-
version or an 8-to-256 bit conversion, the number of digits or bytes to be con-
verted, and the starting digit or byte.
Digit number: 3 2 1 0
0
R: First result word
There can be anywhere from 1 to 32 result words, depending upon the type of
conversion process and number of digits/bytes being converted. The result
words must be in the same data area.
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
S: Source word
C: Control word
R: First result word
Step program areas Subroutines
OK
Specifies the first digit/byte to be converted
4-to-16: 0 to 3 (digit 0 to 3)
8-to-256: 0 or 1 (byte 0 or 1)
Number of digits/bytes to be converted
4-to-16: 0 to 3 (1 to 4 digits)
8-to-256: 0 or 1 (1 or 2 bytes)
Conversion process
0: 4-to-16 bits (digit to word)
1: 8-to-256 bits (byte to 16-word range)
S
CIO 0 to CIO 6143
W0 to W511
H0 to H511
A0 to A959
Section 3-11
MLPX(076)
@MLPX(076)
Not supported
Interrupt tasks
OK
C R
A448 to A959
