Appendices
A-1-4 Timer and Counter Instructions
Instruction Mnemonic
HUNDRED-MS TIM ---
TIMER (BCD)
TIMX 550
(Binary)
TEN-MS TIMER TIMH 015
(BCD)
TIMHX 551
(Binary)
ONE-MS TMHH 540
TIMER (BCD)
TMHHX 552
(BCD)
A-10
Code Symbol/Operand
TIM/TIMX(550) operates a decrementing timer with
TIM
units of 0.1-s. The setting range for the set value
N
(SV) is 0 to 999.9 s for BCD and 0 to 6,553.5 s for
binary (decimal or hexadecimal).
S
N: Timer number
Timer input
S: Set value
TIMX(550) Timer PV
N
S
Completion
Flag
N: Timer number
S: Set value
Timer Input Turned OFF before Completion Flag
Turns ON
Timer input
Timer PV
Completion
Flag
TIMH(015)/TIMHX(551) operates a decrementing
TIMH(015)
timer with units of 10-ms. The setting range for the
N
set value (SV) is 0 to 99.99 s for BCD and 0 to
S 655.35 s for binary (decimal or hexadecimal).
N: Timer number
Timer input
S: Set value
Timer PV
TIMHX(551)
N
S
Completion
Flag
N: Timer number
S: Set value
Timer Input Turned OFF before Completion Flag Turns
ON
Timer input
Timer PV
Completion
Flag
TMHH(540)/TMHHX(552) operates a decrementing timer with
TMHH(540)
units of 1-ms. The setting range for the set value (SV) is 0 to
N
9.999 s for BCD and 0 to 65.535 s for binary (decimal or hexa-
S
decimal).
N: Timer number
The timing charts for TMHH(540) and TMHHX(552) are the
S: Set value
same as those given above for TIMH(015).
Timer input ON
TMHHX(552)
N
S
Timer PV
N: Timer number
Completion
S: Set value
Flag
Timer Input Turned OFF before Completion
Flag Turns ON
Timer input
Timer PV
Completion
Flag
Function
SV
SV
SV
SV
OFF
SV
0
ON
OFF
ON
OFF
SV
0
ON
OFF
CJ2 CPU Unit Software User's Manual
Execution
Location
condition
Output Required
Output Required
Output Required
