Appendices
Address
Name
Words Bits
A518 to --- Operation
A520 End Time
A523 --- Total Power
ON Time
A526 A526.00 Serial Port
Restart Bit
A527 A527.00 Online Edit-
to ing Disable
A527.07 Bit Validator
A527.09 Online Edit-
ing Disable
Bit
A528 A528.00 Serial Port
to Error Flags
A528.07
A529 --- FAL/FALS
Number for
System
Error Simu-
lation
A-152
Function
The time that operation stopped as a result of changing
the operating mode to PROGRAM mode is stored here
in BCD.
A518.00 to A518.07: Seconds (00 to 59)
A518.08 to A518.15: Minutes (01 to 59)
A519.00 to A519.07: Hour (00 to 23)
A519.08 to A519.15: Day of month (01 to 31)
A520.00 to A520.07: Month (01 to 12)
A520.08 to A520.15: Year (00 to 99)
If an error occurs in operation, the time of the error will
be stored. If the operating mode is then changed to
PROGRAM mode, the time that PROGRAM mode was
entered will be stored.
Contains the total time that the PLC has been on in 10-
hour units. The data is stored in binary and it is updated
every 10 hours. To reset this value, overwrite the cur-
rent value with 0000 hex.
This word is not cleared at startup, but it is cleared to
0000 when the Memory Corruption Detected Flag
(A395.11) goes ON.
Turn this bit ON to restart the RS-232C port. (Do not
use this bit when the port is operating in Peripheral Bus
Mode.)
This bit is turned OFF automatically when the restart
processing is completed.
The Online Editing Disable Bit (A527.09) is valid only
when this byte contains 5A.
To disable online editing from the CX-Programmer, set
this byte to 5A and turn ON A527.09.
(Online editing refers to changing or adding to the pro-
gram while the PLC is operating in MONITOR mode.)
Turn this bit ON to disable online editing. The setting of
this bit is valid only when A527.00 to A527.07 have
been set to 5 A.
These flags indicate what kind of error has occurred at
the RS-232C port; they are automatically turned OFF
when the RS-232C port is restarted.
(These flags are valid in Serial Gateway mode. They
are not valid in peripheral bus mode and only bit 5 is
valid in NT Link mode.)
Only the following bits are valid in Serial PLC Link
Mode.
Polling Unit:
Bit 5: ON for timeout error.
Polled Units:
Bit 3: ON for framing error.
Bit 4: ON for overrun error.
Bit 5: ON for timeout error.
These bits can be cleared by the CX-Programmer.
Set a dummy FAL/FALS number to use to simulate the
system error using FAL(006) or FALS(007).
When FAL(006) or FALS(007) is executed and the num-
ber in A529 is the same as the one specified in the
operand of the instruction, the system error given in the
operand of the instruction will be generated instead of a
user-defined error.
Status
after Status at
Settings
mode
change
See Function col- Retained Retained
umn.
0000 to FFFF Retained Retained
hexadecimal
OFF to ON: Restart Retained Cleared
5 A: Retained Cleared
A527.09 enabled
Other value:
A527.09 disabled
ON: Disabled Retained Cleared
OFF: Not disabled
Bits 0 and 1: Not Retained Cleared
used.
Bit 2: ON for parity
error.
Bit 3: ON for framing
error.
Bit 4: ON for overrun
error.
Bit 5: ON for timeout
error.
Bits 6 and 7: Not
used.
0001 to 01FF hex: Retained Cleared
FAL/FALS numbers
1 to 511
0000 or 0200 to
FFFF hex: No
FAL/FALS number
for system error sim-
ulation. (No error will
be generated.)
CJ2 CPU Unit Software User's Manual
Write timing/
Related flags,
startup
settings
See Function
column.
---
---
A527.09
A527.00 to
A527.07
---
---
