Instruction Mnemonic
DOUBLE ZCPL 116
AREA RANGE
COMPARE
SIGNED ZCPS 117
AREA RANGE
COMPARE
DOUBLE ZCPSL 118
SIGNED
AREA RANGE
COMPARE
CJ2 CPU Unit Software User's Manual
Code Symbol/Operand
ZCPL(116)
CD
LL
UL
CD: Compare
data (2 words)
LL: 1st word of
lower limit
UL: 1st word of
upper limit
ZCPS(117)
CD
LL
UL
CD: Compare
data (1 word)
LL: Lower limit of
range
UL: Upper limit of
range
ZCPSL(118)
CD
LL
UL
CD: Compare
data (2 words)
LL: 1st word of
lower limit
UL: 1st word of
upper limit
Function
Compares the 32-bit unsigned binary value in CD and CD+1
(word contents or constant) to the range defined by LL and
UL and outputs the results to the Arithmetic Flags in the Aux-
iliary Area.
Compares the 16-bit signed binary value in CD (word con-
tents or constant) to the range defined by LL and UL and out-
puts the results to the Arithmetic Flags in the Auxiliary Area.
Compares the 32-bit signed binary value in CD and CD+1
(word contents or constant) to the range defined by LL and
UL and outputs the results to the Arithmetic Flags in the Aux-
iliary Area.
Appendices
Execution
Location
condition
Output Required
Output Required
Output Required
