Selecting Standard (9600: 1,7,2,E)
If Standard (9600: 1,7,2,E) is selected, the following communications settings will be used uncondition-
ally.
• Baud rate: 9,600 bps
• Start bits: 1 bit
• Data length: 7 bits
• Stop bits: 2 bits
• Parity: Even
• Mode (serial communications mode): Host link
Note The mode and other settings will be disabled.
Use the following procedure to set the communications to custom settings.
1
Select the Custom Option for the communications settings.
2
Select the serial communications mode in the Mode Field.
3
Make other settings.
Selecting Custom
If custom settings is selected, the following baud rates, parameters, and modes can be selected.
Baud Rate (When Custom Settings Is Selected)
Setting
115200
57600
38400
19200
9600 (default)
Format (When Custom Settings Is Selected)
Selected data
7,1,E
7,1,O
7,1,N
7,2,E (default)
7,2,O
7,2,N
8,1,E
8,1,O
8,1,N
8,2,E
8,2,O
8,2,N
CJ2 CPU Unit Software User's Manual
Meaning
11,5200 bps 4800
57,600 bps 2400
38,400 bps 1200
19,200 bps 600
9,600 bps 300
Data length Stop bits
7 1 bit
2 bits
8 1 bit
2 bits
Setting Meaning
4,800 bps
2,400 bps
1,200 bps
600 bps
300 bps
Parity
Even A619.02 (Serial Port Settings
Changing Flag)
Odd
None
Even
Odd
None
Even
Odd
None
Even
Odd
None
9 PLC Setup
Related flags and
words
A619.02 (Serial Port
Settings Changing
Flag)
Related flags and words
9-25
