Appendices
Instruction Mnemonic Code
EIGHT-DIGIT STR8 602
NUMBER TO
@STR8
ASCII
SIXTEEN- STR16 603
DIGIT NUM-
@STR16
BER TO ASCII
ASCII TO NUM4 604
FOUR-DIGIT
@NUM4
NUMBER
ASCII TO NUM8 605
EIGHT-DIGIT
@NUM8
NUMBER
A-34
Symbol/Operand
Converts an 8-digit hexadecimal number (#0000 0000 to
STR8
#FFFF FFFF) to ASCII data (8 characters).
S
15
D
S
S+1
S: Numeric
D: ASCII text
Hexadecimal: #12345678
ASCII
15
D
D+1
D+2
D+3
Converts a 16-digit hexadecimal number (#0000 0000 0000
STR16
0000 to #FFFF FFFF FFFF FFFF) to ASCII data (16 charac-
ters).
S
D
15
S
C
S: Numeric
8
S+1
D: ASCII text
S+2 4
S+3 0
Hexadecimal: #1234567890ABCDEF
ASCII
15
D
D+1
D+2
D+3
D+4
D+5
D+6
D+7
Converts 4 characters of ASCII data to a 4-digit hexadecimal
NUM4
number.
S
15
D
S
S+1
S: ASCII text
D: Numeric
ASCII
Hexadecimal
15
D
Converts 8 characters of ASCII data to an 8-digit hexadecimal
NUM8
number.
S
15
D
S
S+1
S: ASCII text
S+2
D: Numeric
S+3
ASCII
Hexadecimal
15
D
D+1
Function
12 11 8 7 4 3 0
5 6 7 8
1 2 3 4
8 7 0
31 32
33 34
35 36
37 38
12 11 8 7 4 3 0
D E F
9 A B
5 6 7
1 2 3
8 7 0
30 31
32 33
34 35
36 37
38 39
41 42
43 44
45 46
8 7 0
31 32
33 34
12 11 8 7 4 3 0
1 2 3 4
8 7 0
31 32
33 34
35 36
37 38
12 11 8 7 4 3 0
5 6 7 8
1 2 3 4
CJ2 CPU Unit Software User's Manual
Execution
Location
condition
Output Required
Output Required
Output Required
Output Required
