Appendices
Address
Name
Words Bits
A10140 --- High-speed
and Counter 2 Ring
A10141 Counter Maxi-
mum Value
A10142 --- High-speed
and Counter 3 Ring
A10143 Counter Maxi-
mum Value
A10144 --- Interrupt input 0
and latched PV
A10145
A10146 --- Interrupt input 1
and latched PV
A10147
A10148 --- Interrupt input 2
and latched PV
A10149
A10150 --- Interrupt input 3
and latched PV
A10151
A10152 --- Interrupt input 4
and latched PV
A10153
A10154 --- Interrupt input 5
and latched PV
A10155
A10156 --- Interrupt input 6
and latched PV
A10157
A10158 --- Interrupt input 7
and latched PV
A10159
Note In CJ-series PLCs, the following flags are provided in a special read-only area and can be specified with the labels given
in the table. These flags are not contained in the Auxiliary Area. Refer to 6-21 Condition Flags and 6-22 Clock Pulses for
details.
A-148
Function
Contain the ring counter maximum values when high-speed
counters 2 is used as ring counters. These values are cleared to 0
if Linear Mode is used.
Lower 4 digits: A10140, Upper 4 digits: A10141
Contain the ring counter maximum values when high-speed
counters 3 is used as ring counters. These values are cleared to 0
if Linear Mode is used.
Lower 4 digits: A10142, Upper 4 digits: A10143
When there is an input for interrupt input 0, the PV of pulse output
0 or the PV of high-speed counter input 0 is stored. The PV imme-
diately before the interrupt input task is started is read and saved.
Lower 4 digits: A10144, Upper 4 digits: A10145
When there is an input for interrupt input 1, the PV of pulse output
1 or the PV of high-speed counter input 1 is stored. The PV imme-
diately before the interrupt input task is started is read and saved.
Lower 4 digits: A10146, Upper 4 digits: A10147
When there is an input for interrupt input 2, the PV of pulse output
2 or the PV of high-speed counter input 2 is stored. The PV imme-
diately before the interrupt input task is started is read and saved.
Lower 4 digits: A10148, Upper 4 digits: A10149
When there is an input for interrupt input 3, the PV of pulse output
3 or the PV of high-speed counter input 3 is stored. The PV imme-
diately before the interrupt input task is started is read and saved.
Lower 4 digits: A10150, Upper 4 digits: A10151
When there is an input for interrupt input 4, the PV of pulse output
4 or the PV of high-speed counter input 4 is stored. The PV imme-
diately before the interrupt input task is started is read and saved.
Lower 4 digits: A10152, Upper 4 digits: A10153
When there is an input for interrupt input 5, the PV of pulse output
5 or the PV of high-speed counter input 5 is stored. The PV imme-
diately before the interrupt input task is started is read and saved.
Lower 4 digits: A10154, Upper 4 digits: A10155
When there is an input for interrupt input 6, the PV of pulse output
6 or the PV of high-speed counter input 6 is stored. The PV imme-
diately before the interrupt input task is started is read and saved.
Lower 4 digits: A10156, Upper 4 digits: A10157
When there is an input for interrupt input 7, the PV of pulse output
7 or the PV of high-speed counter input 7 is stored. The PV imme-
diately before the interrupt input task is started is read and saved.
Lower 4 digits: A10158, Upper 4 digits: A10159
Status Write timing/
Status at
after mode Related flags, set-
startup
change tings
Cleared Cleared Refreshed when
INI(880) instruction
is executed to
change ring counter
maximum value.
Cleared Cleared Refreshed when
INI(880) instruction
is executed to
change ring counter
maximum value.
Cleared Cleared When input interrupt
occurs
Cleared Cleared When input interrupt
occurs
Cleared Cleared When input interrupt
occurs
Cleared Cleared When input interrupt
occurs
Cleared Cleared When input interrupt
occurs
Cleared Cleared When input interrupt
occurs
Cleared Cleared When input interrupt
occurs
Cleared Cleared When input interrupt
occurs
