Appendices
Address
Name
Words Bits
A598 A598.00 FPD Teach-
ing Bit
A598.01 Equals Flag
for Back-
ground
Execution
A600 to --- Macro Area
A603 Input Words
A604 to --- Macro Area
A607 Output
Words
A619 A619.02 Serial Port
Settings
Changing
Flag
A-156
Function
Turn this bit ON to set the monitoring time automatically
with the teaching function.
While A598.00 is ON, FPD(269) measures how long it
takes for the diagnostic output to go ON after the execu-
tion condition goes ON. If the measured time exceeds
the monitoring time, the measured time is multiplied by
1.5 and that value is stored as the new monitoring time.
The teaching function can be used only when a word
address has been specified for the monitoring time
operand.
Turns ON if matching data is found for an SRCH(181)
instruction executed in the background.
When MCRO(099) is executed, the contents of the four
specified source words (starting from the 1st input
parameter word) are copied here. The contents of the
four copied words are then passed to the subroutine.
After the subroutine specified in MCRO(099) has been
executed, the results of the subroutine are transferred
from A604 through A607 to the specified destination
words. (output parameter words)
ON while the RS-232C port's communications settings
are being changed. This flag will be turned ON when
STUP(237) is executed and it will be turned OFF after
the settings have been changed.
Status
after Status at
Settings
mode
change
ON: Teach monitor- Cleared Cleared
ing time
OFF: Teaching func-
tion off
ON: Search data Cleared Cleared
found in table
OFF: Search data
not found
Input data: Cleared Cleared
4 words
Output data: Cleared Cleared
4 words
ON: Changing Retained Cleared
OFF: Not changing
CJ2 CPU Unit Software User's Manual
Write timing/
Related flags,
startup
settings
---
---
---
---
---
