Instruction Mnemonic Code
STEP DEAC- SE 785
TIVATE
@SE
READ SET TSR 780
TIMER
@TSR
SET STEP TSW 781
TIMER
@TSW
SFC ON SFCON 789
SFC OFF SFCOFF 790
SFC PAUSE SFCPR 793
WITH
RESET
SFC PAUSE SFCPRN 791
WITH NO
RESET
CJ2 CPU Unit Software User's Manual
Symbol/Operand
Makes the specified step of subchart inactive to end execution of
SE(784)
the actions.
D
The present value of the Step Time specified by S is stored start-
TSR(780)
ing at D.
S
D
The present value of the Step Timer specified by S is changed to
TSW(781)
the value specified starting at D.
S
D
Restarts execution of an SFC task that was ended or paused
SFCON(789)
using one of the other SFC Task Control Instructions.
N
N: SFC task
number
Ends execution of an SFC task. The status of all outputs is held.
SFCOFF(790)
When execution of the SFC task is restarted, it is executed from
the initial step.
N
N: SFC task
number
Pauses execution of an SFC task. The status of all outputs is
SFCPR(793)
reset.
N
N: SFC task
number
Pauses execution of an SFC task. The status of all outputs is held.
SFCPRN(791)
N
N: SFC task
number
Function
Appendices
Execution
Location
condition
Output Required
Output Required
Output Required
Output Required
Output Required
Output Required
Output Required
A-79
