Omron CJ2 CPU UNIT SOFTWARE User Manual page 638

Appendices
Address
Name
Words Bits
A540 A540.00 Pulse Out-
put 0 Reset
Bit
A540.08 Pulse Out-
put 0 CW
Limit Input
Signal Flag
A540.09 Pulse Out-
put 0 CCW
Limit Input
Signal Flag
A541 A541.00 Pulse Out-
put 1 Reset
Bit
A541.08 Pulse Out-
put 1 CW
Limit Input
Signal Flag
A541.09 Pulse Out-
put 1 CCW
Limit Input
Signal Flag
A542 A542.00 Pulse Out-
put 2 Reset
Bit
A542.08 Pulse Out-
put 2 CW
Limit Input
Signal Flag
A542.09 Pulse Out-
put 2 CCW
Limit Input
Signal Flag
A543 A543.00 Pulse Out-
put 3 Reset
Bit
A543.08 Pulse Out-
put 3 CW
Limit Input
Signal Flag
A543.09 Pulse Out-
put 3 CCW
Limit Input
Signal Flag
A544 --- Interrupt
Counter 4
Counter Set
Value
A545 --- Interrupt
Counter 5
Counter Set
Value
A546 --- Interrupt
Counter 6
Counter Set
Value
A-154
Function
The pulse output 0 PV (contained in A276 and A277)
will be cleared when this bit is turned ON.
This is the CW limit input signal for pulse output 0,
which is used in the origin search. To use this signal,
write the input from the actual sensor as an input condi-
tion in the ladder program and output the result to this
flag.
This is the CCW limit input signal for pulse output 0,
which is used in the origin search. To use this signal,
write the input from the actual sensor as an input condi-
tion in the ladder program and output the result to this
flag.
The pulse output 1 PV (contained in A278 and A279)
will be cleared when this bit is turned ON.
This is the CW limit input signal for pulse output 1,
which is used in the origin search. To use this signal,
write the input from the actual sensor as an input condi-
tion in the ladder program and output the result to this
flag.
This is the CCW limit input signal for pulse output 1,
which is used in the origin search. To use this signal,
write the input from the actual sensor as an input condi-
tion in the ladder program and output the result to this
flag.
The pulse output 2 PV (contained in A322 and A323)
will be cleared when this bit is turned ON.
This is the CW limit input signal for pulse output 2,
which is used in the origin search. To use this signal,
write the input from the actual sensor as an input condi-
tion in the ladder program and output the result to this
flag.
This is the CCW limit input signal for pulse output 2,
which is used in the origin search. To use this signal,
write the input from the actual sensor as an input condi-
tion in the ladder program and output the result to this
flag.
The pulse output 3 PV (contained in A324 and A325)
will be cleared when this bit is turned ON.
This is the CW limit input signal for pulse output 3,
which is used in the origin search. To use this signal,
write the input from the actual sensor as an input condi-
tion in the ladder program and output the result to this
flag.
This is the CCW limit input signal for pulse output 3,
which is used in the origin search. To use this signal,
write the input from the actual sensor as an input condi-
tion in the ladder program and output the result to this
flag.
This word is used for an input interrupt in counter mode.
Set the count until the interrupt task is executed. When
interrupt counter 4 counts the number of pulses set
here, interrupt task 144 will be executed.
This word is used for an input interrupt in counter mode.
Set the count until the interrupt task is executed. When
interrupt counter 5 counts the number of pulses set
here, interrupt task 145 will be executed.
This word is used for an input interrupt in counter mode.
Set the count until the interrupt task is executed. When
interrupt counter 6 counts the number of pulses set
here, interrupt task 146 will be executed.
Status
after Status at
Settings
mode
change
--- Retained Cleared
--- Retained Cleared
--- Retained Cleared
--- Retained Cleared
0000 to FFFF hex Retained Cleared
0000 to FFFF hex Retained Cleared
0000 to FFFF hex Retained Cleared
CJ2 CPU Unit Software User's Manual
Write timing/
Related flags,
startup
settings
---
---
---
---
---
---
---
