10-4 Unit Management Functions

10-4-1 Basic I/O Unit Management

Setting the Input Response Time for Basic I/O Units
The input response times for Basic I/O Units can be set by Rack and Slot number. Increasing the
input response time reduces the effects of chattering and noise. Decreasing the input response time
(but keeping the pulse width longer than the cycle time) allows reception of shorter input pulses.
Note Pulses shorter than the cycle time can be input with a High-speed Input Unit. Refer to 10-2-4 High-speed
Inputs for details.
Basic I/O
Unit
CPU Unit
PLC Setup
When using the CX-Programmer, make the settings in the areas for specifying the response time for
racks 0 to 7 on the Unit Settings Tab Page.
Auxiliary Area Flags and Words
Name
I/O Response Times in Basic I/O
Units
CJ2 CPU Unit Software User's Manual
Input response time
Basic I/O
I/O refreshing
Unit
Address
A220.00 to
A259.15
Input response time
Pulses shorter than the input
response time are not
received.
CPU Unit
Description
Contains the current I/O response times for CJ-series
Basic I/O Units.
10 CPU Unit Functions
I/O refreshing
