iSitePower-M (MAP05A1, MAB05B1)
User Manual
B
B.1 Preparing a Cord End Terminal
Figure B-1 Preparing a cord end terminal
(1) Cable
B.2 Preparing an OT Terminal
● Avoid scratching the core wire when stripping a cable.
● The cavity formed after the conductor crimp strip of the OT terminal is crimped
● Wrap the wire crimping area with heat shrink tubing or insulation tape. The
● When using a heat gun, protect the equipment from being scorched.
Issue 06 (2023-04-24)
Preparing Cables and Terminals
NO TICE
must wrap the core wires completely. The core wires must contact the OT
terminal closely.
heat shrink tubing is used as an example.
Copyright © Huawei Digital Power Technologies Co., Ltd.
(2) Cord end terminal

B Preparing Cables and Terminals

(3) Crimping tool
