iSitePower-M (MAP05A1, MAB05B1)
User Manual

5.4 (Optional) Backhaul Module iIOT-WAC0412

The iIOT-WAC0412 is an IoT outdoor 4G wireless backhaul module. It reports
alarms and signals to the FusionSolar Smart PV Management System in wireless
communication mode.
● The 4G wireless backhaul module may be disconnected or fail to connect to the
● Recommended SIM card monthly data package: 500 MB
Figure 5-9 4G wireless backhaul module
(1) Indicator
Table 5-9 Indicator status description
Color
Green
Issue 06 (2023-04-24)
NO TICE
network in an enclosed metal environment or in a base station with weak
signals.
Status
Steady on
Blinking slowly
On for 0.8s and
off for 0.064s
alternately
Blinking slowly
On for 2s and off
for 0.064s
alternately
Blinking slowly
On for 0.6s and
off for 0.064s
alternately
Copyright © Huawei Digital Power Technologies Co., Ltd.
(2) SIM card installation
position
Remarks
Abnormal
Normal
Normal
Normal
5 Components
(3) Module installation
port
Description
The backhaul
module is not
running.
The backhaul
module is not
registered with
the network.
The backhaul
module is
registered with
the network.
The backhaul
module is
transmitting data.
