iSitePower-M (MAP05A1, MAB05B1)
User Manual
Pin
6
7
8

5.3 (Optional) AC Parallel Box ACDB220-90-1B

The AC parallel box is used for paralleling of power modules to increase the
system power. A maximum of three power modules can be connected in parallel.
Figure 5-7 ACDB220-90-1B
Figure 5-8 ACDB220-90-1B interior
(1) Ground point on the
door
(4) AC input circuit
breaker
Issue 06 (2023-04-24)
Signal
Null
CANH
CANL
Copyright © Huawei Digital Power Technologies Co., Ltd.
Description
CAN bus high level
CAN bus low level
(2) Ground bar
(5) N wiring terminal
5 Components
(3) Cable bags
(6) AC output circuit
breaker
45
