iSitePower-M (MAP05A1, MAB05B1)
User Manual
Figure 5-6 Ports on the battery module
(1) Alignment boss
(4) Heat sink
Communications Port
Table 5-7 Communication port description
Port
COM
NOTE
Table 5-8 COM pin definition
Pin
1
2
3
4
5
Issue 06 (2023-04-24)
The preceding port is protected by security mechanisms.
Signal
START+
START–
Null
Null
Null
Copyright © Huawei Digital Power Technologies Co., Ltd.
(2) COM port
(5) Ground points
Communications
Parameter
Baud rate: 250 kbit/s
Description
Manual ON/OFF switch
-
5 Components
(3) Terminals for battery
module cascading
Communicati Description
ons Protocol
CAN Communicati
ons port for
a battery
module
