Figure 10-42 Installing battery signal cables
When a communications terminal is connected to a single network cable, the
waterproof rubber plug must be installed for the hole with no cable routed.
Otherwise, the waterproof performance may be affected and the device will be
damaged.
----End

10.5.3 Installing an AC Output Power Cable

● The live (L) wire and neutral (N) wire of an AC power cable must be correctly
● The PE wire of an AC power cable must be grounded.
● Do not reversely connect AC output power cables.
