Setting Address Dip Switches - Huawei iSitePower-M MAP05A1 User Manual

iSitePower-M (MAP05A1, MAB05B1)
User Manual
● Before installing parallel cables, correctly set the address DIP switches for the
● The address DIP switches take effect only after the devices are restarted. Set
● Pin 1 (M/S) indicates whether the product is a master or slave. When Pin 1 is
● When only one product is used, set Pin 1 to ON.
● The default address is 0 (Pin 1 to Pin 4: OFF).
Step 1 Open the power module maintenance compartment.
Figure 8-1 Opening the maintenance compartment
Issue 06 (2023-04-24)
8

Setting Address DIP Switches

NO TICE
master and slave products.
the DIP switches when the devices are powered off (AC and DC inputs are
disconnected, and the devices are shut down by pressing the black start
button).
set to ON, the product is a master product. Otherwise, the product is a slave
product. Pins 2–4 (A–C) indicate the high-speed CAN communication addresses
in a parallel system.
