Chapter 3: Jumpers and Connectors
SATA Connector 1
Connector size: 1 x 7 = 7-pin header
Connector location: CN3
1
7
Pin
Definition
1
GND
3
SATA-TXN0
5
SATA-RXN0
7
GND
Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
SATA-TXP0
4
SATA_PCIE_DETP0
6
SATA-RXP0
SATA Connector 2
Connector size: 1 x 7 = 7-pin header
Connector location: CN11
1
7
Pin
Definition
1
GND
3
SATA-TXN1
5
SATA-RXN1
7
GND
20
Pin
Definition
2
SATA-TXP1
4
SATA_PCIE_DETP1
6
SATA-RXP1
VTC 7252-7C4IP User Manual
