Chapter 3: Jumpers and Connectors
GPS Battery Connector
Connector type: 1x2 2-pin header
Connector location: J3
1
2
Pin
Definition
1
GND
2
RTC_BAT
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
SATA Connector
Connector type: Standard Serial ATA 7P (1.27mm, SATA-M-180)
Connector location: CN8
1
7
Pin
Definition
1
GND
3
SATA_TXN0
5
SATA_RXN0
7
GND
26
Pin
Definition
2
SATA_TXP0
4
GND
6
SATA_RXP0
VTC 1011 Series User Manual
