Chapter 2: Jumpers and Connectors
SATA Connector
Connector type: Standard Serial ATA 7P (1.27mm, SATA-M-180)
Connector location: SATA1
1
7
Pin
Definition
1
GND
3
SATA_TXN0_C
5
SATA_RXN0_C
7
GND
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
SATA_TXP0_C
4
GND
6
SATA_RXP0_C
SATA Power Connector
Connector type: 1x2 2-pin header, JST 2.5mm pitch
Connector location: J2
2
1
Pin
Definition
1
VCC5
2
GND
22
NISE 105U User Manual
