C O N F I G U R A T I O N
2
MinPad Configuration
Recording Interval parameter
This parameter specifies the message output interval into the log file when
the MinPad FN key (pressed for 1–5 seconds) activates data logging. This
setting is used not only when logging a single log file, but also when
logging receiver data in AFRM mode. Values are 1–86400 seconds.
The default value is one second.
Elevation Mask for Log File parameter
This parameter specifies the minimum elevation angle for the satellites
whose data will be put in the receiver files logged via MinPad when
pressing FN.
The default value is five degrees.
File Name Prefix parameter
This parameter specifies what prefix will be added to the names of the
receiver files created via MinPad when pressing FN. The prefix can be up to
20 characters long.
The default value is "log".
Log file names have the following structure:
<prefix><month><day><sequential alphabet letter>
The file name depends on both the file creation time (month and day) and
additional letter suffixes to avoid confusion between files created on the
same day.
Always Append to the File parameter
2-26 Prego Operator's Manual
Figure 2-35. Receiver Configuration – MinPad
