Antenna Offset Measurements - Javad Prego Operator's Manual

Antenna-2
www.javad.com
Figure 3-1. Antenna Offset Measurements
Table 3-1. Antenna-2 Offset Measurements
Antenna Radius
0.122m
0.399 ft
S E T U P A N D M E A S U R I N G
A, Vertical C, Slant Offset
Offset (L1)
0.054m 0.021m
0.176 ft 0.069 ft
Prego Operator's Manual 3-3
Prego Setup
(L1)
