Gps External Antenna Rf Connector; Usb Connector; Spread Spectrum/Gsm Modem Connector Specifications; External Antenna Connector Specifications - Javad Prego Operator's Manual

Type
TNC

GPS External Antenna RF Connector

Type
TNC

USB Connector

Number
1
www.javad.com
Spread Spectrum modem (JNS) or GSM modem connector type is TNC RF
connector.
Table B-6. Spread Spectrum/GSM Modem Connector Specifications
Signal Name
Modem I/O
The external antenna connector type is a TNC RF connector with an
Applied Engineering Product part number
6001-7051-003.
Table B-7. External Antenna Connector Specifications
Signal Name
Ant_IN
The USB connector (Figure B-4) is a sealed receptacle, 5 pin connector
with ODU part number G80F1C-T05QF00-0000.
Table B-8 gives the USB connector specifications.
Table B-8. USB Connector Specifications
Signal Name
Dir
I/O RF input from modem
antenna
Dir
I RF input from LNA, 60 mA
at 5.0 volts
Figure B-4. USB Connector
Dir
Not used
A P P E N D I X
Connector Specifications
Details
Details
Details
Prego Operator's Manual B-11
