A P P E N D I X
B
Connector Specifications

Serial RNGR Connector

The RNGR connector (Figure B-3) is a sealed receptacle, 7 pin connector
with ODU part number G80F1C-T07QC00-0000.
Table B-4 gives the RNGR connector specifications.
Number
1
2
3
4
5
6
7

Radio (Modem) RF Connector

The Pacific Crest PDL (UHF) modem connector type is a BNC Bulkhead
Jack RF connector with an Applied Engineering Product part number of
6501-7051-003.
Table B-5. Pacific Crest PDL (UHF) Modem Connector Specifications
Type
BNC
B-10 Prego Operator's Manual
Figure B-3. RNGR Connector
Table B-4. RNGR Connector Specifications
Signal Name
GND -
CTS I
RTS O
RXD I
TXD O
Signal Name Dir
Modem I/O I
Dir Details
Not Used
Signal ground
Clear to send
Request to send
Receive data
Transmit data
Not used
Details
RF input from PDL antenna
