S E T U P A N D M E A S U R I N G
3
Measuring with the Prego

Setting up an RTK Rover

3-18 Prego Operator's Manual
Use the following steps to set up an Prego RTK Rover station. You
should already have programmed the modem. Figure 3-13 shows the
hardware setup for a Rover station with the Prego on a bipod.
Figure 3-13. Prego Rover Station Setup
1.Set up the Rover station receiver's antenna as described in "Setup
Antenna" on page 3-1.
2.Connect the receiver and your computer as described in "Connecting
the Prego and a Computer" on page 2-4.
3.Click Configuration->Receiver.
4.Select the Positioning tab and set the Position Masks, Elevation mask
(degrees) parameter to 15 (Figure 3-10 on page 3-15).
