S E T U P A N D M E A S U R I N G
3
Measuring with the Prego
Notice: For Pacific Crest PDL (UHF) modems, use a 38400 baud rate. For
Spread Spectrum 915 MHz/2.4 GHz modems, use a 19200 baud rate.
3-20 Prego Operator's Manual
• Input drop-down list – select desired differential correction format.
• Period (sec) – leave as is.
• Baud rate drop-down list – select a baud rate (i.e., the rate with
which differential messages will be transmitted from modem to
receiver).
Figure 3-15. Rover Configuration – Ports
7.Click Apply.
8.Click OK to close the Receiver Configuration screen.
9.On the main screen (Figure 3-16), check the LQ field to ensure the
receiver obtains differential corrections. Usually, the receiver will start
to output the coordinates of the antenna's phase center among with the
solution type in 10–30 seconds.
Figure 3-16. PCView Main Screen
