A P P E N D I X
A
Creating Scripts
Type in the appropriate commands, pressing Enter or clicking Send
7.
Command after each one. See Table A-1 for these commands.
%%set,dev/ser/c/rate,38400
%%set,dev/ser/c/echo,/cur/term
%%set,dev/ser/c/imode,echo
%%set,cur/term/eoff,QUIT
%%set,cur/term/echo,/dev/null
%%set,cur/term/imode,echo
%%set,cur/term/echo,/dev/ser/c
Click Save Script.
8.
Click Close Editor.
9.
Once you have created a script file,
1. Click Load Script on the Manual Mode dialog box.
Navigate to the folder that contains your script file.
1.
Select the appropriate script file and click Load.
2.
A-2 Prego Operator's Manual
Table A-1. Script Commands
To Create Daisy Chain To End Daisy Chain
QUIT
%%set,cur/term/imode,cmd
%%set,dev/ser/c/echo,/dev/null
%%set,dev/ser/c/imode,cmd
%%set,dev/ser/c/rate,38400
%%set,cur/term/rate,115200
