Pcview Main Screen; Click File->Connect - Javad Prego Operator's Manual

2.
3.
4.
• Set the Connection mode (Direct).
• Set the port for your computer (typically COM1) from the Port drop-down
www.javad.com
Start PCView on your computer. The PCView main screen displays
(Figure 2-1).
Click File->Connect (Figure 2-2).
On the Connection Parameters dialog box, select the following parameters
and click Connect (Figure 2-3 on page 2-6):
list.
Figure 2-1. PCView Main Screen
Figure 2-2. Click File->Connect
C O N F I G U R A T I O N
Connecting the Prego and a Computer
Prego Operator's Manual 2-5
