C O N F I G U R A T I O N
2
Radio Configuration
Click Close and then Exit to quit the program (Figure 2-29).
12.
Notice: The Base station and internal Prego PDL radios must be configured with
the same Channels, Radio Link characteristics (except Digisquelch),
and Serial Interface parameters.
Open PCView.
13.
Click File->Connect.
14.
On the Connection Parameters screen, select a baud rate of 38400 and
15.
enable the Manual mode only check box (Figure 2-30), then click Connect.
On the Manual Mode screen, write the following commands, pressing Enter
16.
(or clicking Send command) after each command. When finished, you
should have six responses (Figure 2-31 on page 2-23).
2-22 Prego Operator's Manual
Figure 2-29. Click Close then Exit
Figure 2-30. Connection Parameters – Manual Mode Only
